Merida Scultura 200
Product Details
Brand:
MERIDA
Highlights:
- Lightweight aluminium frame
- Full carbon tapered fork
- Shimano Sora gearing
- FSA Omega chainset with compact gearing
- Promax mechancial disc brakes
- Maxxis Pursuer 25c Kevlar bead folding tyres
The Scultura has always been the powerhouse of any Merida sponsored or supported ProTour teams powering them to world tour stage victories. The Lite frame uses cutting edge aluminium technology - 6066 series triple butted and hydroformed aluminium tubing with smooth welding to deliver a light responsive frame. The tapered full carbon fork delivers precise steering.
Specification
Promotion Ribbon
- Repositioned
Frame
- Lite - Hydroformed triple butted 6066 aluminium with smooth welding. Tapered head tube, Pressfit BB Standard, 142 x 12mm axle standard. Max tyre size 700 x 28c
Fork
- Scultura CF2 Disc; Full carbon; tapered steerer. Max tyre size: 700 x 28c
Gears
- 18
Shifters
- Shimano Sora
Front Derailleur
- Shimano Sora
Rear Derailleur
- Shimano Sora; GS
Bottom Bracket
- FSA BB-AL86/Ø19
Chain
- KMC M99
Chainset
- FSA Omega; 50-34 tooth chainset. Crank length: 165mm (XXS), 170mm (XS,S), 172.5mm (S/M,M/L), 175mm (L/XL)
Cassette
- Microshift CS-9S; 11-28 teeth; 9 speed
Brake Lever
- Shimano Sora
Front Brake
- Promax DSK-330R mechanical disc brake caliper with Promax 160G 160mm rotor
Rear Brake
- Promax DSK-330R mechanical disc brake caliper with Promax 160G 160mm rotor
Grip
- Merida Road Comp
Handlebar
- Merida Expert SL, aluminium; Width: 380mm(XXS), 400mm (XS-S), 420mm (S/M-M/L), 440mm (L-XL)
Stem
- Merida Comp CC; aluminium; 31.8mm diameter; -6 degree rise - Stem length: 80mm (XXS/XS), 90mm (S), 100mm (SM/ML), 110mm (L/XL)
Head Set
- Merida M2339 Neck
Pedal
- Not included
Saddle
- Merida Comp SL with V-mount
Seat Post
- Merida Comp CC; aluminium; 27.2mm diameter; 5mm lay back
Wheel Size
- 700c
Rims
- Merida Comp SL; 17mm inner rim width; 22mm rim depth; aluminium
Spokes
- Black stainless
Front Hub
- Joytech D981SB; 100x12mm; 28 Spokes, 6 bolt
Rear Hub
- Joytech D982TSE-R; 142x12mm; 28 spokes; 6 bolt
Front Tyre
- Maxxis Pursuer; 700 x 25C; Kevlar bead; folding
Rear Tyre
- Maxxis Pursuer; 700 x 25C; Kevlar bead; folding
Colour
- Green/Black
Geometry
