Merida One-Sixty FR 400

£2 333.33
Available to order
Size
Please choose
Colour
Please choose
Available to order
Save this product for later
Have questions?
Share this product with your friends
Merida One-Sixty FR 400
Product Details
Brand: MERIDA
Highlights:
  • DVO Jade X D3 shock
  • SR Durolux 38 Air fork
  • 4 Piston Tektro Gemini brakes with 203mm rotors.
  • Continental Kryptotal 2.4"tyres
  • Shimano Cues 1x10 drivetrain
Wallet friendly ripper, built for bike park fun and rated for category 5 use. 180mm up front and 171mm out back with 4 pot stopping power.



The hardcore cousin of the One-Sixty 6000 MBUK's Enduro Bike of the year. Of the One-Sixty 6000 they said: "it was the Merida’s proportions, supportive suspension and electrifying ride feel that finally clinched it.“The fun we had riding some of the gnarliest trails around Dolceacqua, skimming over jagged rocks and drifting loose turns, meant it had to be the winner.”Totally planted, thoroughly sorted and outrageously capable. Merida's design team have taken that prize winning pedigree and turned up the fun to 11. Built for ripping bike parks, the One-Sixty FR comes mullet across all sizes and delivers more travel;180mm up front and 171mm of coil sprung travel at the rear. The essence of the One-Sixty FR is full on fun at a value for money price, these bikes are not garage queens, they are for endless hours of sending it, Based around a tough aluminium frame the component selection is focussed on delivering the best tyres, brakes and suspension possible at the price, not on lightweight kit that won't last the course. The One-Sixty FR is designed for the toughest possible conditions and is rated to Category 5 and comes with a 5 year frame warranty. The Agilometer sizing concept takes account of riding style, allowing riders to run a longer or shorter reach frame independently of their height, while suspension becomes more progressive as you size up, all with long-travel dropper posts. Wire Port cable routing plus reliable threaded bottom bracket round out the package,

Specification

Frame
  • Lite III - Aluminium, Next Generation enduro geometry, internal cable routing, long seat post insert depth. Boost axle standard, threaded BB, trail mount and bottle bosses, flip chip for mullet or 29er. Max tyre size - 2.5"
Shock
  • DVO Jade X D3; coil with spring rates Xshort & Short: 300, Mid: 350, Long: 400, Xlong: 450
Fork
  • SR Suntour Durolux 38 RC; Air; 180mm travel; Tapered; 44mm fork offset; Max tyre size: 29" x 2.6"
Gears
  • 10
Shifters
  • Shimano CUES U6000
Rear Derailleur
  • Shimano CUES U6000; GS
Bottom Bracket
  • Samox BSA 24mm EB2401
Chain
  • KMC xGlide
Chainset
  • Merida Expert TR II; 32 tooth chainset with Merida Expert TR ISCG05; Crank length - 165mm (all sizes)
Cassette
  • Shimano LG300; 11-48 teeth; 10 speed
Brake Lever
  • Tektro Gemini HD-M535
Front Brake
  • Tektro Gemini HD-M535; 4 piston hydraulic disc brake caliper with Tektro TR203-45; 203mm rotor
Rear Brake
  • Tektro Gemini HD-M535; 4 piston hydraulic disc brake caliper with Tektro TR203-45; 203mm rotor
Grip
  • Merida Comp EC
Handlebar
  • Merida Expert TR II; aluminium; 780mm wide; XS/S 18mm rise; M/L/XL 30mm rise
Stem
  • Merida Expert eTRII; aluminium; 35mm diameter; 0 degree rise - Length - 40mm (all sizes)
Head Set
  • Acros ICR Merida external neck; Upper and lower IPS sealing
Saddle
  • Merida Comp SL; V-mount - made with 25% recycled material
Seat Post
  • Merida Expert TR II; 34.9mm diameter; 0mm layback; XShort/Short: 150 mm seat post travel - Mid: 170 mm seat post travel - Long: 200 mm seat post travel - XLong: 230 mm seat post travel
Wheel Size
  • 29" / 27.5"
Rims
  • Merida Comp TR II; 28mm inner rim width; aluminium; Tubeless ready (tubeless tape and valves not included); front 29"; rear 27.5"
Spokes
  • Double Butted Black stainless
Front Hub
  • Shimano TC500-B; 110 x 15mm; 32 spoke; Centerlock
Rear Hub
  • Shimano TC500-HM-B; 148 x 12mm; 32 spoke; Centerlock
Front Tyre
  • Continental Kryptotal-F; 29" x 2.4"; Kevlar bead; TR; Enduro casing; Soft Compound
Rear Tyre
  • Continental Kryptotal-R; 27.5" x 2.4"; Kevlar bead; TR; Enduro Casing; Soft Compound
Colour
  • Silk Dark Red/Grey/Black
Season
  • 2025

Geometry
