- RockShox Judy TK fork
- Shimano 2 x 9 drivetrain
- Sophisticated aluminium frame
- Hydraulic disc brakes
- Tapered head tube
- Internal cable routing
Merida's heartland has always been bombproof aluminium hardtails. Half a century of frame building experience counts for a lot. All Big Nine and Big Seven models use a sophisticated TFS frame featuring the latest technology: full internal cable routing for a clean, neat set up, tapered headtube offering the potential for future upgrades inboard disc brake mounts protect the brake and maximise stopping power As much Shimano componentry as possible has been added to complement the modern frame and enhance reliability. There are a wide range of sizes; Big Nine for taller riders and Big Seven for shorter riders with a healthy overlap between the two. For riders in the middle, riding style can be taken into account. If you are looking for speed and efficiency choose a Big Nine, if you are looking for agility choose a Big Seven.
Specification
- Price Crash
- TFS III - 6061 aluminium, double butted and technoformed. Tapered head tube. Chain stay mounted disc brake. Internal cable routing. Mudguard and kick stand mounts. BSA threaded BB. 135mm x 9mm axle. Max. tyre size 29" x 2.25"
- RockShox Judy TK; Coil; 100mm travel. Lockout; 46mm offset. Max. tyre size: 29" x 2.25"
- 18
- microSHIFT SL-M850
- Shimano FD-M2020-TS
- Shimano RD-M370
- Shimano BB-UN100
- KMC M99
- Shimano MT101-2; 36-22 tooth chainset. Crank length: 175mm (M,L,XL,XXL)
- Shimano CS-HG200; 11-32 teeth; 9 speed
- Power DS-100HT
- Power DS-100HT; 2 piston hydraulic disc brake caliper with Shimano RT10; 160mm rotor
- Power DS-100HT hydraulic disc brake caliper with Shimano RT10; 160mm rotor
- Merida EC
- Merida CC; aluminium; 690mm wide; 15mm rise
- Merida CC; aluminium; 31.8mm diameter; 6 degree rise - Stem length: 70mm (S), 80mm (M), 90mm (L), 100mm (XL), 110mm (XXL)
- Merida M2345
- VP Components, VPE-891
- Merida Sport comfort
- Merida Comp CC; aluminium; 30.9mm diameter; in-line
- 29"
- Merida CC; 17mm inner rim width; aluminium
- Black steel
- Shimano TX505; 100x9mm; 32 spokes; Center lock
- Shimano TX505; 135x9mm; 32 spokes; Center lock
- Merida K1080; 29" x 2.2"; wire bead
- Merida K1080; 29" x 2.2"; wire bead
- Dark Grey/Silver
- 2023
Geometry
